Bar Rail FAQs

What parts do I need to build a bar foot rail?

There are four main components in a foot rail system that all fit together to provide a comfortable place to rest your feet: railing/tubing, brackets, end caps, and elbows.

To get started, follow the steps below.

  1. Decide which finish you'd like to use for your bar foot rail. Our most popular bar rail finishes include brushed stainless steel, polished stainless steel, and oil rubbed bronze. Click here for a complete list of available finishes.
  2. Determine the tubing length you'll need for your entire bar. Don't forget, it's always better to have extra than to end up short!
  3. Choose any elbows or fittings you might need to connect the tubing around corners or bends.
  4. Select the bracket style that will support your tubing. For optimal support, you'll need a bracket at both ends of your bar rail and at three-foot increments for the duration of its length.
  5. Choose the end caps or flanges you like best to finish off your new bar rail.
I want a wood bar rail. Will metal brackets and end caps work?

Yes! All metal brackets are compatible with our wooden tubing.

When choosing an end cap, select items marked as "external." External fittings are components that fit around the outer diameter the tubing, as opposed to sliding inside. Our wooden tubing is solid, so you must use end caps that fit externally around the wood.

We currently offer three external end cap styles: Decorative External End Cap, Flat External End Cap, and a Center Post End Cap.

My bar doesn't match the standard tubing lengths on your site. What should I do?

Creating a custom length bar rail is easy. If you need a longer rail, use an internal bar rail splicing sleeve to connect two pieces of tubing. Cover the seam between two joined pieces by placing a bracket over the joint.

To make your rail shorter, use a hack saw, a chop saw with a metal cutting blade to cut a piece of standard size tubing until you have the length you need. We always recommend you use a miter box any time you are using a hack saw to keep your cuts as straight possible. If the ends of the tube look or feel rough, use a wire wheel or file to smooth them. You can easily cover any rough ends with an external end cap or a bracket.

My bar is curved. Is there a bar rail that will work?

Absolutely! Curved railings are made-to-order. We roll tubing in-house to your exact specs to ensure accuracy, quality, and a fast turnaround time! Contact a Bar Rail Expert to get started.

To create your custom quote we will need:

  1. Detailed drawing(s) of your bar. Make sure all applicable measurements (particularly length, width and radii of curves) are included.
  2. The bar rail finish(es) you’ve selected.
  3. Your choice of bracket style.
  4. Your choice of end cap style.

Send the information using one of the following methods:

Email: sales@kegworks.com

USPS Mail:
KegWorks
Attn: Sales Director
1460 Military Road, Rear Building
Kenmore, NY 14217

Fax: 716.856.9675 (ATTN: Sales Director)

Once we receive your information, we'll be in touch with an estimate within 24 hours.

Please note, once you place your order it may take up to three weeks for your custom rails to arrive.

Can I have my bar rail order expedited?

If you'd like information about additional delivery options for your order, send us an email or give us a call! We're happy to provide you with a shipping estimate.

Email:
Click here to use our email form. We will reply to you as quickly as possible!

Call:
877-636-3673
Outside the US: 716-856-9675
Monday - Friday, 9:00 a.m. - 6:00 p.m. EST

Transform a dull, boring bar area into a luxurious place to entertain guests with just a few added features. KegWorks bar foot rails provide comfort when sitting at the bar and are the perfect solution to dress up your bar area. Bar rails add a rich element to the bar that will spice up an indoor space or outdoor patio area. Just a few accessories can create a classy modern feel.

A bar foot rail system includes tubing, brackets, end caps and sometimes elbows, which connect together easily. Our bar rail instructions, complete with how-to video, will guide you through the simple installation process. These stylish and functional accents will compliment your bar area and provide comfort to guests for years to come.
