For those that have access to the back of their bar face, bar mount brackets are a great option for both a classy look and an added level of convenience.
Bar mount brackets are a great option for those that can’t (or don’t want) to drill holes into their floors, and keep it clear of mounts that can stub toes. They also make cleaning your floor easier because you can sweep or mop under your foot rail without impediments.
This bar mount bracket is made from 304 stainless steel with a brushed finish, and will precisely match your Brushed Stainless Steel two-inch outside diameter bar rail tubing.
You can create a custom look with bar mounted brackets because they allow you to choose the height of your bar rail. This is the perfect solution for those wanting to mount their bar rail higher than the standard 6”. Be sure to carefully measure where each bracket will be placed before drilling into your bar. For proper support, bar brackets should be placed at each end of the tubing, plus one for every 4-foot increment.
These brackets mount directly to the face of the bar via three mounting screws and a 2 ¾" bolt that mounts from behind the bar to create a modern look where your metal bar rail tubing looks as if it is floating next to the bar. The threaded hanger bolt is what provides the added weight support to secure your foot rail in place.
For help deciding which bracket will work best for your bar project, check out our bar foot rail brackets guide for more information on each of the options.
Installation instructions:
Bar mount brackets include a 2 ¾" hanger bolt to properly support the weight. To ensure adequate support, a solid backing at least 3/4” deep is required.
- Measure & mark holes for mounting screws and for the threaded bolt.
- Drill hole in bar diewall for the threaded rod.
- Attach bracket from behind bar face using hanger bolt and secure with nut and washer.
- Attach brackets to the face of the bar with the 3 mounting screws.
- Secure tubing to bracket by fastening set screws through hole in the bottom of bracket.
For more detailed instructions on how to install bar rail read our guide to planning & installing.
Care & Maintenance:
Care and maintenance of bar foot rail varies by finish. Given the nature of the product, typical wear and tear may be noticed with your bar rail over time, such as scuffs, scratches and dirt. Our guide to cleaning & maintenance on how to properly prep, clean & maintain all bar rail finishes.
-
- Made of 304 Stainless Steel with brushed finish
- For use with 2" Outside Diameter bar rail tubing
- Attaches to the face of the bar from the rear
- Brackets should be used at both ends of rail tubing, plus one at every 4' increment
- Mounting screws & hanger bolt for back of bar included
- Suitable for indoor use only (Clear coat protection available by request)
-
- Bracket Width: 8.00”
- Bracket Height: 6.76”
- Opening Diameter: 2.01” (for 2” OD tubing)
- Wall to Center of Tubing (Horizontal Center Point): 6.94”
- Floor to Center of Tubing (Vertical Center Point): 5.70”
-
- (3) #10 1-1/2" Mounting Screws
- (1) #8 3/4" Self-Drilling Set Screw
- (1) 2 ¾" Hanger Bolt
- (1) Hex Nut 5/16” - 18
- (1) USS Flat Washer - 5/16”
- Download Spec Sheet
-
Attention CA Residents:
Prop 65 Warning >
You Might Also Like
The KegWorks Difference We're Your Favorite Drinking Buddy
Entertain & Inspire
We believe in creating and sharing good beverages. And having a damn good time doing it.
Educate & Inform
From troublshooting draft systems to crafting the perfect cocktail. We've got you covered.
Unique Product Selection
Your one-stop shop for the unique bar products you just have to have.
Exceed Expectations
Here to help. We aim to be the go-to source for all drink enthusiasts.
Customer Reviews
- Reviews
- Questions
Only 4 stars because I got it to work
It’s looks fine, but no way this was designed correctly. The “ set screws “ are self tapping sheet metal screws that can’t be ******* into hard stainless. They heated up , seized up, and snapped off. I had to tap out holes to make it work. Should have a true hex headed or Allen set screw. Also, how do you get to the underside to install set screws with a drill without pre assembling, not enough clearance. There were skimpy directions at best. Luckily I diy a good bit. Last obvious challenge was end caps that required/suggested electrical tape or JB weld to secure them. Come on Keg Works, bush…… Materials are good quality though, the only saving grace for this project
Everyone loves this addition
You won't be disappointed in the off the floor style.
These are commercial grade. Brackets do not disappoint, they are strong and will support many feet and the bar rail! Getting behind the bar to bolt them may prove a little difficult, but we knew this going in. Exactly the style we wanted.
Not a 1/4 oz pour
Pour was not 1/4 oz it was more like 3/4 oz. Ended up returning for a refund. ??
Beautiful product
Product has a nice finish. Customer Service was very helpful in getting this ordered and delivery was quick. Looks great! Thank you.
A plus
Well made. Very nice.
Worked perfectly! Very Happy.
the products is high quality and I highly recommended it
Perfect
Just what I was looking for.
better than what I expected
new floor new bars
your product is great love the look. love the through bolt connection, very secure
Metric Bolts
Overall the Foot rail I ordered from KEgWorks is excellent. high quality materials and finish. The installation is straight forward but one thing to know, and the reason for the 1 star, is that the thread in the supports are METRIC (M8 I believe) not standard US threads. I needed longer bolts for my application and checked with the customer service dept. They told me they were 5/16 course threads. As I was assembling things I realize the bolts I bought would not fit. I had to re tap the supports. Luckily I had a tap set.
