Perlick - ITEM # 40030

Low Profile US Sankey Keg Coupler - D System

Roll Over Image to Zoom

Click to View Larger

$59.99

In stock and ready to ship.

Dealing with a tight clearance above your keg? This low-profile US Sankey (D System) coupler is just what you need to dispense most North American brews.

    Overview

    Setting up your draft beer system in small refrigerator can be a challenge – but it’s not impossible. This low-profile keg coupler is designed for tight clearance installations.

    The keg coupler’s job is to connect your CO2 tank to the keg so the gas can push the beer up through the beer line. The bottom of the coupler attaches to the keg valve, and the beer line and air line slide over the horizontal hose nipples and secured with screw clamps.

    With standard keg couplers, you need a few inches of clearance above the top of your keg. But with a low-profile design, this keg coupler only sticks up about ¾ inch above the rim of the keg. So you’ll have an easier time installing and operating your keg setup in limited space.

    This keg coupler uses the US Sankey (D System), which is the valve system of choice for just about all beers brewed in North America, including Budweiser, Michelob, Busch, Miller Lite, Coors, Killians, Sam Adams, Labatt, and more. To be safe, check our handy coupler list to find out which system your favorite beer calls for.

    Made from brass with a chrome-plated finish, this keg coupler is very durable and easy to install. It’s a great choice for both home and commercial bars.

    Features
    • US Sankey (D System) keg coupler
    • Connects the gas tank, keg, and beer lines to allow for pressurized dispensing
    • Low-profile design – only sticks up ¾ inch above the keg
    • Ideal for tight clearance installations
    • Horizontal gas and beer line hose nipples
    • Works for majority of North American beers
    • Made from chrome-plate finish
    • Easy to install and use
    • Great for home or commercial use

     Free Expert Support

     877.636.3673

    Contact Customer Care
    Specifications
    Specs
    • Height: 2.125"
    • Width: 4" (Barb to Barb)
    • Chrome plated forged brass body
    • Chrome plated probe
    • Barb inlet for 5/16” Inside Diameter gas hose
    • Barb outlet for 3/16” Inside Diameter beer hose
    Shipping & Delivery

    Related Products
    Customer Reviews
    4.8 / 5.0
    16 Reviews
    5 Stars
    4 Stars
    3 Stars
    2 Stars
    1 Star
    13
    2
    1
    0
    0
    Quality
    4.9 / 5
    Value
    4.6 / 5
    Easy to Clean
    4.2 / 5
    Would you recommend this product?
    Yes! I would recommend this product. (16)
    Would you recommend this product?
    Yes! I would recommend this product.
    Quality
    5 / 5
    Value
    5 / 5
    Easy to Clean
    5 / 5
    Works perfect for small height
    August 24, 2016
    San antonio, Texas
    Purchased
    1 year ago
    Would you recommend this product?
    Yes! I would recommend this product.
    Quality
    5 / 5
    Value
    5 / 5
    Saves space
    Bought this Sankey tap so it would allow me to get two Pony Kegs in my converted chest freezer. Works great saves several inches in hight of a traditional Sankey tap.
    February 13, 2017
    McMinnville, OR, US
    Purchased
    1 year ago
    Would you recommend this product?
    Yes! I would recommend this product.
    Quality
    5 / 5
    Value
    4 / 5
    Engage kegerator!!!
    April 28, 2017
    sacramento, CA, US
    Purchased
    1 year ago
    Would you recommend this product?
    Yes! I would recommend this product.
    Quality
    5 / 5
    Value
    5 / 5
    Gave me the room at the top of the keg that I needed
    The couplers that came with the Glaros 3 tap Kegerator I just purchased from Costco.com left no room at the top of the inside of my Kegerator -- they were rubbing and flexing just to put them in place inside the unit. So much so that I feared the pressure would make them leak eventually, not to mention that it was a pain to try to slide them around to adjust the CO2 or switch out the kegs.
    The Perlick low profile Sankey couplers I bought were just the fix I needed. They give me an extra two or more inches.
    Just wish they came in stainless steel, or, if Perlick does make them in SS, wish Kegworks.com carried them. No big deal though. I'm guessing the chrome (or whatever it is) will do fine.

    Great product.
    July 2, 2018
    San Marcos, CA, US
    Purchased
    3 weeks ago
    Would you recommend this product?
    Yes! I would recommend this product.
    Quality
    5 / 5
    Value
    4 / 5
    Way more user-friendly than standard couplers
    Great coupler, makes it much easier to tap kegs where there is minimum clearance between the keg and refer. Also makes it easier to move the keg around when checking how much beer you have remaining.
    January 11, 2018
    Maryville, TN, US
    Purchased
    1 year ago
    Would you recommend this product?
    Yes! I would recommend this product.
    Quality
    5 / 5
    Value
    5 / 5
    Awesome addition to a keg fridge
    This coupler easily gives you back 5-6 inches of top clearance over a standard coupler. Was able to add shelves above both kegs in my converted keg fridge. Solid construction and easy to connect. Will buy a second one very soon.
    December 20, 2016
    VA, US
    Purchased
    1 year ago
    Would you recommend this product?
    Yes! I would recommend this product.
    Quality
    5 / 5
    Value
    4 / 5
    Easy to Clean
    3 / 5
    great for a tight fit keg box
    I purchased 2 of these so I could fit 1/2bbl kegs in my keg box. they work great
    September 14, 2016
    US
    Purchased
    1 year ago
    Would you recommend this product?
    Yes! I would recommend this product.
    Quality
    5 / 5
    Value
    5 / 5
    Keg Coupler
    This came as discribed in add. Quality product.
    Was easy to order and came very quickly
    April 18, 2018
    cedarville, MI, US
    Purchased
    3 months ago
    Would you recommend this product?
    Yes! I would recommend this product.
    Quality
    4 / 5
    Value
    4 / 5
    Easy to Clean
    4 / 5
    Love the low profile!!
    June 13, 2016
    Conshohocken , PA, US
    Purchased
    over 3 years ago
    Would you recommend this product?
    Yes! I would recommend this product.
    Quality
    5 / 5
    Value
    5 / 5
    Add ball lock connects. Super easy.
    August 19, 2017
    Cranford , NJ, US
    Purchased
    11 months ago
    Questions & Answers
    Start typing your question and we'll check if it was already asked and answered. Learn More
    Browse 9 questions Browse 9 questions and 64 answers
    Why did you choose this?
    Kegworks Store
    Brand new kegerator is not tall enough to fit a 5gal with a regular tap. Disappointing, but need to resolve.... This appears to do the trick.
    David P on Jun 15, 2018
    mini fridge converting to kegerator tight space
    Christopher R on Apr 9, 2018
    Brand new kegerator is not tall enough to fit a 5gal with a regular tap. Disappointing, but need to resolve.... This appears to do the trick.
    David P on Jun 15, 2018
    This low profile coupler let me have one keg on the step up part of my keezer and another keg in the main area which has full depth.
    Michael on May 2, 2018
    mini fridge converting to kegerator tight space
    Christopher R on Apr 9, 2018
    Works great in beer dispensators when the tall keg coupler hits the condenser fan. Allows the keg to be pushed all the way to the back of the chiller.
    Brian H on Feb 27, 2018
    Love it coupler. I bought another one after using the first one for a couple months. Easy on and off with no beer splatter.
    Matthew M on Nov 3, 2017
    Works great in home made kegerator so kegs will fit
    jason b on Sep 29, 2017
    perfect for fitting a fat short 5gal keg with a std 5gal keg in my kegerator.
    Kent Z on May 31, 2017
    Ideal component for my application which is to apply organic chemicals for disinfecting, pest control, and odor control. Pressurize the keg to 50 psi then pulse mist the chemical. Similar to a shot of perfume.
    Steve R on May 2, 2017
    New freezer system was too shallow
    Michael M on Mar 3, 2017
    Our church inherited a restaurant-grade kegerator that almost definitely had one of these originally, but no longer. Wedging the existing connector in causes some very un-Christian language (from the vicar!), hoping this will address that.
    Graham G on Jan 30, 2017
    Not enough clearance in top of converted chest freezer for 15.5 gallon keg to fit under closed lid. This low profile tap should let keg fit.
    MICHAEL W C on Jan 22, 2017
    I've gone through too many cheap 'economy' couplers. Thought I'd give this a try.
    Mark D on Nov 9, 2016
    True Kegerator has a line cooling ledge that prevents 1/2 and 1/6 barrels from fitting properly. These low profile couplers allow the kegs to be slid all the way to the back of the kegerator.
    Paul S on Oct 5, 2016
    Limited space in my kegorator
    Paul F on Aug 11, 2016
    More clearance at the top of my kegerator.
    Thomas S on Jul 22, 2016
    height limitation on cooler
    Bill W on Jul 17, 2016
    Great solution for tight cooling units. Allows me to vary my beer types and keg sizes.
    Francis T on Jul 16, 2016
    Needed space in my Kegerator.
    Gregory V on Jul 14, 2016
    Make 4 1/6 Sankey fit in my 7cu mabe kegerator.
    Monica Guadalupe A on Jun 30, 2016
    Low clearance in cooler
    bill M on Jun 14, 2016
    TO FIT KEG IN LOW PROFILE COOLER
    WILLIAM H on Jun 6, 2016
    Regular tap was too tall to fit in my kegerator.
    Frederick B on May 20, 2016
    easier operation and doesn't kink the line
    KEN D on May 12, 2016
    price
    Vincent B on Apr 1, 2016
    to cut down on the height in the fridge
    shawn m on Dec 17, 2015
    My current sankey adapters are too tall and I have to lean the keg.
    James W on Nov 20, 2015
    We needed a shorter style keg coupler to fit an old beer meister.
    Daniel S on Nov 1, 2015
    for keg filling, I'm hoping it'll be quicker and require less effort to switch couplers between kegs since there's no lever.
    andrew c on Oct 28, 2015
    to make fitting a keg in my kegerator easier
    Tom M on Oct 16, 2015
    This low profile coupler let me have one keg on the step up part of my keezer and another keg in the main area which has full depth.
    Michael on May 2, 2018
    Works great in beer dispensators when the tall keg coupler hits the condenser fan. Allows the keg to be pushed all the way to the back of the chiller.
    Brian H on Feb 27, 2018
    Will this fit the 1/4 keg tall/slim size?
    TIM M. on Apr 4, 2017
    BEST ANSWER: I have used this on 5 gallon and 15.5 gallon kegs with no problem. I had to use it because the kegerator we have is not as tall as other ones and the standard coupler with the beer line coming off the top would cause the hose to kink closed as it hit the top of the inside of the fridge.

    With this one, both lines come out just a little above the keg handles.
    How do you untap kegs using this style of coupler?
    katie w on Jan 10, 2018
    BEST ANSWER: By "untap" I assume you mean to stop the flow of beer by releasing the ball inside the keg coupler hole. The Sankey coupler has an upper and lower portion. The lower portion actually screws down inside of the keg opening and the upper portion then screws down inside of the lower portion to actually "tap" the keg. Make sure your tap handle is closed first! To "untap", simply screw the upper portion counter clockwise until it is loose inside of the lower portion (approximately one quarter to one third of a turn). To completely remove the Sankey coupler from the keg, keep turning counter clockwise until lose and removable.
    Cheers, Freshkeg.
    How to attach coupler?
    A shopper on Jun 10, 2016
    BEST ANSWER: Pretty easy really, just start threading the coupler into the Keg like normal till it stops (about a 1/2 turn), then you have to push down on the coupler firmly and continue to twist the coupler to tap the keg. I would recommend that you turn on your CO2 after you make it past the first part of coupling so as to minimize beer back flowing into your CO2 line. Over all, a great coupler for those with limited fridge height.
    Besides being a little more expensive than the standard couplers, are there any drawbacks to this coupler over the traditional ones?
    Also, what other parts are necessary to use this coupler. I assume it is necessary to change your tubing for the CO2 and beer (eliminate the threaded connections and attach the tubing directly to the hose adapters)?
    Bill R on Jun 11, 2018
    BEST ANSWER: I've used these for years and really like them. I find them easier to operate (i.e., tap/untap) than standard couplers. Also, I like that there is more clearance above the keg -- that's an issue for me as I am cramming two 1/6 kegs into a small kegerator that has barely enough space for a standard coupler. I like the look of these as well.

    No other parts are necessary. When I went to these, I just cut the tubing where the old threaded connectors were located and attached the tubing to these couplers and tr-used the old hose clamps.

    That all being said, if you don't need the space and don't mind how the standard couplers operate, then the extra expense is probably not worth it.
    How Do you flush the line with this coupler? It doesn't seem to come apart like a standard coupler. Or does it? Thanks.
    A shopper on May 25, 2018
    BEST ANSWER: You can take some of it apart but I simply turn off my gas, drop the coupler (with both lines still attached) into a drain bucket and run the line cleaning solution through the lines AND the coupler at the same time. I'm not if it makes a difference if the coupler is compressed or extended, just observe and make sure the solution is draining into the bucket. I run one or two bottles of the solution through the system, followed by at least four bottles of clean water. I've heard of people cleaning the beer spigot in place as well by turning it upside down, on the tower, opening the handle, and putting a hose over the tip. I prefer to remove and take it apart to clean it (just easier).

    Cheers from "freshkeg".
    Hi all,

    I just purchased one of these and have not used it yet. What is the best way to clean it after use?

    I'm a homebrewer and only have experience with Corny kegs.
    chrisjm on Sep 2, 2017
    BEST ANSWER: Hi Chris, cleaning is pretty simple. You have two options. You can soak the coupler in diluted beer line cleaning solution and use a faucet brush to clean the outlets. Or you can clean from the coupler to the faucet with the Super Deluxe Cleaning Kit that includes a sankey flusher. If you have any further questions, feel free to reach out to our customer care team at 877-636-3673. Cheers!
    Super Deluxe Beer Line Cleaning Kit - 32oz Liquid
    Super Deluxe Beer Line Cleaning Kit - 32oz Liquid
    Super Deluxe Beer Line Cleaning Upgrade Kit
    Super Deluxe Beer Line Cleaning Upgrade Kit
    Super Deluxe Draft Beer Line Cleaning Kit - 1lb No-Rinse Powder
    Super Deluxe Draft Beer Line Cleaning Kit - 1lb No-Rinse Powder
    WILL THIS LOW PROFILE WORK ON WINE KEGS?
    BRUCE F on Apr 4, 2017
    BEST ANSWER: Hi Bruce, while this coupler will fit any keg with a D coupler connection we do not recommend that you use this coupler for dispensing wine. Keg wine systems should only use all stainless steel contact components, including coupler. The acidity in wine will break down the chrome plating and negatively affect the taste and quality of the wine. I've attached the stainless steel D couplers that we carry. Neither are low-profile but will work perfectly for wine kegs. Cheers!
    US Sankey Keg Coupler - D System - Stainless Steel
    US Sankey Keg Coupler - D System - Stainless Steel
    Economy US Sankey Keg Coupler - D System - Stainless Steel
    Economy US Sankey Keg Coupler - D System - Stainless Steel
    Has anyone changed out the barbs with 1/4 flare fittings? If not, anyone know what the thread size is?
    John O on Jan 23, 2018
    BEST ANSWER: Hi John, the fittings thread size is 1/8” NPT. Cheers!
